| Number of HW-interfaces industrial Ethernet | 1 |
|---|
| Number of HW-interfaces RS-232 | 1 |
|---|
| Number of HW-interfaces RS-422 | 0 |
|---|
| Number of HW-interfaces RS-485 | 0 |
|---|
| Number of HW-interfaces USB | 2 |
|---|
| Number of password levels | 2 |
|---|
| Number of grey-scales/blue-scales of display | 0 |
|---|
| Number of system buttons | 0 |
|---|
| Voltage type of supply voltage | DC |
|---|
| Number of function buttons, programmable | 22 |
|---|
| Number of online languages | 20 |
|---|
| Suitable for safety functions | True |
|---|
| Supporting protocol for TCP/IP | True |
|---|
| Supporting protocol for Modbus | False |
|---|
| Supporting protocol for Data-Highway | True |
|---|
| With colour display | True |
|---|
| Number of pixels, vertical | 480 |
|---|
| With numeric keyboard | False |
|---|
| With alpha numeric keyboard | True |
|---|
| With message indication | True |
|---|
| With message system (incl. buffer and confirmation) | True |
|---|
| Process value representation (output) possible | True |
|---|
| Process default value (input) possible | True |
|---|
| With recipes | True |
|---|
| With printer output | True |
|---|
| Additional software components, loadable | False |
|---|
| Supporting protocol for EtherNet/IP | True |
|---|
| Screen diagonal | 6.5 in |
|---|
| Number of pixels, horizontal | 640 |
|---|
| Useful project memory/user memory | 79000 mb |
|---|
| Supply voltage DC | 18 V |
|---|
| Touch technology | Resistive touch |
|---|
| Power input | DC |
|---|
| Display size | 6.5 in |
|---|
| Luminance | 300 cd/m² |
|---|
| Resolution | 640 x 480, 18-bit color graphics |
|---|
| Keypad function keys | 22 function keys F1...F10 and K1...K12 |
|---|
| Operator input | Touch |
|---|
| Power consumption | 70 W max (2.9A @ 24V DC), 39 W typical (1.6A @ 24V DC) |
|---|
| Display type | Color active matrix, thin-film transistor (TFT) |
|---|
| Memory | 512 MB RAM, 512 MB nonvolatile memory, (approx. 79 MB free user memory) |
|---|
| Touch screen | 8-wire analog resistive, Actuation: 1 mon presses, Operating force: 10...110 g |
|---|
| Operating system | Windows CE 6.0 operating system with or without extended features and microsoft office file viewers |
|---|
| Backlight | CCFL, 50000 hr minimum at 25 ° C (77 °F) field replaceable |
|---|
| Keypad description | Stainless-steel membrane, Numeric, navigation and function keys, Actuation: 1 mon presses, Operating force: 340 g |
|---|
| Software | FactoryTalk view machine edition software, version 6.0 or later, FactoryTalk ViewPoint software, version 1.2 or later |
|---|
| Input voltage | 18...32V DC (24V DC nominal) |
|---|
| Secure Digital (SD) card slot | Hot-swappable card slot supports 1784-SDx and 1784-SDHCx SD cards for transferring files, upgrading firmware, or logging data |
|---|
| Battery (real-time clock) | Battery-backed clock timestA critical data, accuracy is ±2 min per month, Battery life: 4 yr min at 25 °C (77 °F), Field-replaceable: cat. no. 2711P-RY2032 or equivalent CR2032 coin-cell lithium battery |
|---|
| USB ports | Two USB host ports for connecting a USB mouse, keyboard, printer, and USB flash drives that are hot swappable |
|---|
| Communication ports | Ethernet (10/100 Mbps, Auto-MDI/MDI-X), RS-232, (2) USB host, Network interface for optional Ethernet, DH+/DH-485, or ControlNet (scheduled or unscheduled) communication module |
|---|
| Number of HW-interfaces serial TTY | 0 |
|---|
| Number of HW-interfaces parallel | 0 |
|---|
| Number of HW-interfaces other | 0 |
|---|
| Number of interfaces PROFINET | 0 |
|---|
| Number of HW-interfaces Wireless | 0 |
|---|
| Number of buttons with LED | 0 |
|---|
| Supporting protocol for LON | False |
|---|
| Supporting protocol for ASI | False |
|---|
| Supporting protocol for PROFIBUS | False |
|---|
| Supporting protocol for CAN | False |
|---|
| Supporting protocol for INTERBUS | False |
|---|
| Supporting protocol for KNX | False |
|---|
| Supporting protocol for DeviceNet | False |
|---|
| Supporting protocol for SUCONET | False |
|---|
| Supporting protocol for other bus systems | False |
|---|
| Supporting protocol for SERCOS | False |
|---|
| Supporting protocol for INTERBUS-Safety | False |
|---|
| Radio standard Bluetooth | False |
|---|
| Radio standard Wi-Fi 802.11 | False |
|---|
| IO link master | False |
|---|
| Supporting protocol for AS-Interface Safety at Work | False |
|---|
| Supporting protocol for DeviceNet Safety | False |
|---|
| Supporting protocol for Foundation Fieldbus | False |
|---|
| Supporting protocol for PROFINET CBA | False |
|---|
| Supporting protocol for PROFINET IO | False |
|---|
| Supporting protocol for PROFIsafe | False |
|---|
| Supporting protocol for SafetyBUS p | False |
|---|
| Radio standard GPRS | False |
|---|
| Radio standard GSM | False |
|---|
| Radio standard UMTS | False |
|---|
| With SW interfaces | True |
|---|
| Type of display | TFT |
|---|
| Reset and default switches | Provide easy access to diagnostic and repair ops |
|---|
| Network interface | For optional Ethernet, DH+, DH-485, or ControlNet communication module |
|---|
| External storage | Secure Digital (SD) card, cat. no.1784-SDx, supported by hot-swappable SD card slot, USB flash drive that is supported by high-speed, hot-swappable, 2.0 USB host port |
|---|
| FactoryTalk view software | FactoryTalk view machine edition station runtime, version 6.0 or later, is preloaded and activated on each terminal, Single license support for FactoryTalk viewpoint software, version 1.2 or later, gives remote users access to a terminal’s displays via st |
|---|
